Made in Erbil · The KAWAN production storyThink packaging.
Think us.Corrugated boxes · Offset cartons · Labels — made in Erbil.

It starts with the box.Corrugated — the one that carries everything else.
01 · CorrugatedPaper, shaped into strength.Every box starts as flat kraft paper.
Waved into flute.Heat, steam and fluted rolls give the medium its spring.
Three layers: single wall.Liner · flute · liner, glued at every tip with starch.
A second flute.A finer wave on top, for more strength.
Five layers: double wall.For the loads that can’t fail.
Paper arrives on the roll.Kraft liner and fluting medium — tested before they’re used.
Rolls unwind.The mill roll stands feed liner and medium into the line.
Heat opens the paper.Steam-heated drums bring each web to temperature.
The flute is born.Fluted rolls press the medium into waves; starch bonds the first liner.
A moment on the bridge.The single-faced web rests overhead, keeping tension even.
Starch on every tip.The glue unit touches the crest of each flute.
Hot plates set the board.The second liner closes the sandwich; heat cures the bond.
Cut to width. Scored to fold.The slitter-scorer divides the web and presses fold lines.
Sheets, stacked.The cut-off knife cuts to length; the stacker builds the pile.
Printed.The flexo unit lays your brand onto the board.
Creased and slotted.Fold lines pressed, flaps cut free.
Stood up and folded.Four panels close into a tube.
Glued. Flaps closed.The joint holds; the box is square.
Your box.The Kawan Sample Box — five Pantone inks on white liner, B-flute.
02 · OffsetPhotographic colour,
carton scale.Folding cartons for pharma, food and retail.
One plate per colour.Your artwork is separated into cyan, magenta, yellow and black.
Inked, one over the other.Each plate lays down one ink.
Every colour from four inks.Tiny dots, perfectly in register.
Sheet by sheet.The feeder lifts one sheet at a time into the press.
Cyan. Magenta. Yellow. Black.Each printing unit adds one ink.
Spot colour, then coating.Brand colour and protective varnish in the same pass.
Many cartons on every sheet.Printed sheets stack in the delivery.
Cut and creased in one stroke.A steel-rule die cuts every carton on the sheet.
Stripped.The waste skeleton lifts away.
Flat cartons, ready to fold.Every blank identical to the last.
A line of glue.Laid on the side flap as the blank runs through the folder-gluer.
Folded and pressed flat.Delivered flat, packed tight, ready for your line.
Opened into shape.On your packing line, the carton springs square.
Your carton.The Kawan Sample Box — six Pantone inks on white board.
7406 C Yellow300 C BlueBlack 6 C200 C RedBright Green C021 C OrangeProcess CyanProcess Magenta
03 · LabelEight colours. One pass.Self-adhesive labels: face paper on a silicone liner.
Corona treatment.The surface is charged so the ink holds tight.
Eight print units.Six Pantone spot colours plus process cyan and magenta.
One colour each.Every unit adds one ink, perfectly in register.
Cured by UV, instantly.UV lamps after every unit dry the ink before the next.
Die-cut.A rotary die cuts each label — never the liner.
Matrix stripped.The waste around the labels peels away.
Rewound.Finished labels on a roll, ready for your line.
Onto the bottle.Applied on your filling line.
Your label.Same design language as the carton — eight inks, one pass.
One packageThe label on the bottle.
The bottle in the carton.
The carton in the box.
Label, carton and box.From one supplier, under one roof.

Think packaging. Think us.

Tell us what it carries.
We'll build what carries it.

Send us the product, the weight, the journey and the shelf it ends up on — our team comes back with a construction, a dieline and a price.
